Universal Engineering Corporation



Digital Thickness Micrometer (UEC-1004 A)


Digital Thickness Micrometer (UEC-1004 A)

The thickness of sheet is measured as the distance between two circular plane surface, under a steady pressure 1 Kg / cm2 (98.0 Kpa). For rapid and accurate measurement of thickness of paper, board and plastics. Motorized, sturdy, easy to use and “push the button” operation. Digital Display, Mitutoyo (Japan) make add-on type optical transducer. with Resolution 0.01 mm. , with Resolution 0.001 mm.

Thickness Micrometer for Tissue For rapid and accurate measurement of thickness of tissue and other soft material.

The thickness of sheet is measured as the distance between two circular plane surface, under a steady pressure of 0.2 kg dead weight load over a 10 cm2 surface area.



Details

Product Code UEC-1004 A
Equipment Category Physical Property Testing Equipments
Weight 16 Kg
Dimension 46 x 28 x 49 cm.
Applicable Standards SCAN P 7, SCAN P 47, TAPPI T411, CPPA D.4, ISO 534, ISO 3034, FEFCO No.3, DIN 53105, BS 3983, BS 4817
Testing Applications Newsprint (Thickness)
Writing Printing/copier Paper (Thickness)
Duplex And Art Paper (Thickness)
Kraft Liner/fluting Paper/sack (Thickness)
Corrugated Fibre Board Box Board (Thickness)
Corrugated Fibre Board Box Board (Thickness)
Tissue & Soft Material (Thickness)
